LED constant current driving is a fundamental concept in ensuring the stable and efficient operation of LED lighting systems.
Why Constant Current Driving?
LEDs have a non linear voltage current characteristic. Small changes in the forward bias voltage across an LED can cause significant changes in the current flowing through it. If the current is not properly controlled, the LED can be damaged by over current or may exhibit inconsistent brightness. Constant current driving is essential because the brightness of an LED is directly proportional to the current passing through it. By maintaining a constant current, the brightness of the LED remains stable, regardless of variations in the input voltage or the characteristics of the LED itself.
There are different types of constant current drivers, but they all share the common principle of regulating the current flowing through the LEDs. One common type is the linear constant current driver. In a linear driver, a power transistor is used to control the current. The driver compares the actual current flowing through the LED with a reference current. If the actual current is higher than the reference current, the resistance of the power transistor is increased, reducing the current. Conversely, if the actual current is lower, the resistance of the power transistor is decreased to allow more current to flow. This adjustment is continuous, ensuring a constant current output.
Switch mode constant current drivers are also widely used. These drivers operate by rapidly switching the input voltage on and off. They use inductors and capacitors in combination with semiconductor switches (such as MOSFETs) to store and release energy. When the switch is on, current flows through the inductor, storing energy in its magnetic field. When the switch is off, the energy stored in the inductor is released to the LED. The duty cycle of the switch (the ratio of the time the switch is on to the total switching period) is adjusted to control the average current flowing through the LED. This type of driver is generally more efficient than linear drivers, especially for high power applications, as it reduces power losses in the form of heat.
Benefits of Constant Current Driving
Constant current driving offers several advantages. It extends the lifespan of LEDs by preventing over current, which can cause premature failure. It also ensures consistent color output, as the color of an LED can be affected by changes in current. In applications where uniform brightness is crucial, such as in display backlighting or architectural lighting, constant current drivers are essential for providing a stable and even light distribution.
